The 2 operators can be selected from a long list. As a special case, the same digital input can be used as both set and reset, making it
possible to use the same digital input as start/stop. The following settings can be used to set up the same digital input (for example,
DI32) as start/stop.
Table 677: Operators
Parameter
Setting
Notes
Parameter 13-00 SL Controller Mode
[1] On
–
Parameter 13-01 Start Event [0]
True
–
Parameter 13-02 Stop Event [0]
False
–
Parameter 13-40 Logic Rule Boolean 1 [0]
[37] Digital input DI32
–
Parameter 13-42 Logic Rule Boolean 2 [0]
[2] Running
–
Parameter 13-41 Logic Rule Operator 1 [0]
[3] AND NOT
–
Parameter 13-40 Logic Rule Boolean 1 [1]
[37] Digital input DI32
–
Parameter 13-42 Logic Rule Boolean 2 [1]
[2] Running
–
Parameter 13-41 Logic Rule Operator 1 [1]
[1] AND
–
Parameter 13-15 RS-FF Operand S [0]
[26] Logic rule 0
Output from parameter 13-41 Log ic Rule Operator 1 [0].
Parameter 13-16 RS-FF Operand R [0]
[27] Logic rule 1
Output from parameter 13-41 Log ic Rule Operator 1 [1].
Parameter 13-51 SL Controller 1 Event [0]
[94] RS Flipflop 0
Output from parameter 13-15 RSFF Operand S and parameter
13-16 RSFF Operand R.
Parameter 13-52 SL Controller 1 Action [0]
[22] Run
–
Parameter 13-51 SL Controller 1 Event [1]
[27] Logic rule 1
–
Parameter 13-52 SL Controller 1 Action [1]
[24] Stop
–
Parameter 13-15 RS-FF Operand S
Table 678: Parameter 13-15 RS-FF Operand S
13-15 RS-FF Operand S
Default value: Size related
Parameter Type: option, Array [10]
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]
False
[1]
True
[2]
Running
[3]
In range
[4]
On reference
