Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[19]
Warning
[20]
Alarm (trip)
[21]
Alarm (trip lock)
[22]
Comparator 0
[23]
Comparator 1
[24]
Comparator 2
[25]
Comparator 3
[26]
Logic rule 0
[27]
Logic rule 1
[28]
Logic rule 2
[29]
Logic rule 3
[30]
SL time-out 0
[31]
SL time-out 1
[32]
SL time-out 2
[33]
Digital input DI18
[34]
Digital input DI19
[35]
Digital input DI27
[36]
Digital input DI29
N O T I C E
This option is only available in FC 302.
[37]
Digital input DI32
[38]
Digital input DI33
[39]
Start command
[40]
Drive stopped
[41]
Reset trip
[42]
Auto-reset trip
[43]
OK key
[OK] is pressed. Only available on the graphical LCP.
[44]
Reset key
[Reset] is pressed. Only available on the graphical LCP.
[45]
Left key
[◃] is pressed. Only available on the graphical LCP.
[46]
Right key
[▹] is pressed. Only available on the graphical LCP.
[47]
Up key
[▵] is pressed. Only available on the graphical LCP.
[48]
Down key
[▿] is pressed. Only available on the graphical LCP.
AU275636650261en-000101 / 130R0334400 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
