Danfoss VLT AutomationDrive FC 302 Programming Guide

•
•
•
Parameter 16-45 Motor Phase U Current
Table 863: Parameter 16-45 Motor Phase U Current
16-45 Motor Phase U Current
Default value: 0 A
Parameter type: Range, 0 - 10000 A
Setup: All setups
Conversion index: -2
Data type: Int32
Change during operation: True
Shows the motor phase U
RMS
current. Facilitates monitoring of imbalance in the motor currents, detection of weak motor cables or
imbalance in motor windings.
Parameter 16-46 Motor Phase V Current
Table 864: Parameter 16-46 Motor Phase V Current
16-46 Motor Phase V Current
Default value: 0 A
Parameter type: Range, 0 - 10000 A
Setup: All setups
Conversion index: -2
Data type: Int32
Change during operation: True
Shows the motor phase V
RMS
current. Facilitates monitoring of imbalance in the motor currents, detection of weak motor cables or
imbalance in motor windings.
Parameter 16-47 Motor Phase W Current
Table 865: Parameter 16-47 Motor Phase W Current
16-47 Motor Phase W Current
Default value: 0 A
Parameter type: Range, 0 - 10000 A
Setup: All setups
Conversion index: -2
Data type: Int32
Change during operation: True
Shows the motor phase W
RMS
current. Facilitates monitoring of imbalance in the motor currents, detection of weak motor cables or
imbalance in motor windings.
Parameter 16-48 Speed Ref. After Ramp [RPM]
Table 866: Parameter 16-48 Speed Ref. After Ramp [RPM]
16-48 Speed Ref. After Ramp [RPM]
Default value: 0 RPM
Parameter type: Range, -30000 - 30000 RPM
Setup: All setups
Conversion index: 67
Data type: Int32
Change during operation: False
This parameter specifies the reference given to the drive after the speed ramp.
Parameter 16-49 Current Fault Source
Table 867: Parameter 16-49 Current Fault Source
16-49 Current Fault Source
Default value: 0
Parameter type: Range, 0 - 8
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: True
Value indicates source of current faults including short circuit, overcurrent, and imbalance of supply voltage (from left):
1–4 Inverter
5–8 Rectifier
0 No fault recorded
AU275636650261en-000101 / 130R0334 | 505Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
