Parameter 17-51 Input Voltage
Table 930: Parameter 17-51 Input Voltage
Parameter type: Range, 2 - 8 V
Change during operation: False
Set the input voltage to the resolver. The voltage is stated as RMS value. The value is stated in the datasheet for resolvers.
Parameter 17-52 Input Frequency
Table 931: Parameter 17-52 Input Frequency
Parameter type: Range, 2 - 15 kHz
Change during operation: False
Set the input frequency to the resolver. The value is stated in the datasheet for resolvers.
Parameter 17-53 Transformation Ratio
Table 932: Parameter 17-53 Transformation Ratio
17-53 Transformation Ratio
Parameter type: Range, 0.1 - 1.1
Change during operation: False
Set the transformation ratio for the resolver. The transformation ratio is:
Tratioîš‹ = îš‹
Vout
Vin
The value is stated in the datasheet for resolvers.
Parameter 17-56 Encoder Sim. Resolution
Table 933: Parameter 17-56 Encoder Sim. Resolution
17-56 Encoder Sim. Resolution
Default Value: [0] Disabled
Change during operation: False
Set the resolution and activate the encoder emulation function (generation of encoder signals from the measured position from a
resolver). Use this function to transfer the speed or position information from 1 drive to another. To disable the function, select [0]
Disabled.
Set the encoder simulation resolution via parameter 17-58 Encoder Sim. Resolution Adv.
AU275636650261en-000101 / 130R0334522 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
