Parameter 30-02 Wobble Delta Freqeuncy [%]
Table 1065: Parameter 30-02 Wobble Delta Freqeuncy [%]
30-02 Wobble Delta Freqeuncy [%]
Default value: 25%
Parameter type: Range, 0 - 100%
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: True
The delta frequency can also be expressed as a percentage of the center frequency and can thus be maximum 100%. The function is
the same as for parameter 30-01 Wobble Delta Frequency [Hz].
Parameter 30-03 Wobble Delta Freq. Scaling Resource
Table 1066: Parameter 30-03 Wobble Delta Freq. Scaling Resource
30-03 Wobble Delta Freq. Scaling Resource
Default value: [0] No function
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: True
Select the drive input to be used for scaling the delta frequency setting.
Option
Name
Description
[0]*
No function
[1]
Analog input 53
[2]
Analog input 54
[3]
Frequency input 29
N O T I C E
This option is only available in FC 302.
[4]
Frequency input 33
[7]
Analog input X30/11
[8]
Analog input X30/12
[15]
Analog input X48/2
[16]
Analog input X49/1
[17]
Analog input X49/3
[18]
Analog input X49/5
Parameter 30-04 Wobble Jump Frequency [Hz]
Table 1067: Parameter 30-04 Wobble Jump Frequency [Hz]
30-04 Wobble Jump Frequency [Hz]
Default value: 0 Hz
Parameter type: Range, 0 - 20.0 Hz
Setup: All setups
Conversion index: -1
Data type: Uint8
Change during operation: True
The jump frequency is used to compensate for the inertia in the traverse system. If a jump in the output frequency is required at the
boundaries of the wobble sequence, the frequency jump is set in this parameter. If the traverse system has a very high inertia, a high
jump frequency may create a torque limit warning or trip or an overvoltage warning or trip. This parameter can only be changed in
stop mode.
