Parameter 32-07 Absolute Encoder Clock Generation
Table 1118: Parameter 32-07 Absolute Encoder Clock Generation
32-07 Absolute Encoder Clock Generation
Change during operation: True
Select [0] Off when more MCOs are connected to the same absolute encoder. Only 1 MCO is allowed to gener-
ate the clock signal when multiple MCOs are interconnected.
Select [1] On when 1 MCO is connected to 1 absolute encoder.
Parameter 32-08 Absolute Encoder Cable Length
Table 1119: Parameter 32-08 Absolute Encoder Cable Length
32-08 Absolute Encoder Cable Length
Parameter type: Range, 0 - 300 m
Change during operation: True
Set the total cable length (in meters) to avoid that the absolute encoder (SSI) signals come out of synchronization due to signal
delays caused by long encoder cables. VLT® Motion Control Option MCO 305 and VLT® Motion Control Option MCO 302 compen-
sate for the cable delay when the cable length is known.
Parameter 32-09 Encoder Monitoring
Table 1120: Parameter 32-09 Encoder Monitoring
Change during operation: True
Parameter 32-10 Rotational Direction
Table 1121: Parameter 32-10 Rotational Direction
32-10 Rotational Direction
Default value: [1] No action
Change during operation: True
Normally, a positive reference value brings about a positive change of the position. If this is not the case, the reference value can be
reversed internally.
AU275636650261en-000101 / 130R0334590 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
