Parameter 1-22 Motor Voltage
Table 78: Parameter 1-22 Motor Voltage
1-22 Motor Voltage
Default value: Size related
Parameter type: Range, 10 - 1000 V
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: False
N O T I C E
Setting this parameter sets the following parameters to their default settings:
Parameter 1-15 Low Speed Filter Time Const.
Parameter 1-16 High Speed Filter Time Const.
Parameter 1-17 Voltage Filter Time Const.
Parameter 1-24 motor Current
Parameter 1-30 Stator Resistance (Rs)
Parameter 1-31 Rotor Resistance (Rr)
Parameter 1-33 Stator Leakage Reactance (X1)
Parameter 1-34 Rotor Leakage Reactance (X2)
Parameter 1-35 Main Reactance (Xh)
Parameter 1-36 Iron Loss Resistance (Rfe)
Parameter 4-18 Current Limit
Parameter 14-31 Current Lim Ctrl, Integration Time
Parameter 14-43 Motor Cosphi
Parameter 16-36 Inv. Nom. Current
Parameter 16-37 Inv. Max. Current
Parameter 45-33 Alarm High
Parameter 45-62 Load Threshold
Enter the nominal motor voltage according to the motor nameplate data. The default value corresponds to the nominal rated out-
put of the unit.
Parameter 1-23 Motor Frequency
Table 79: Parameter 1-23 Motor Frequency
1-23 Motor Frequency
Default value: 50 Hz
Parameter type: Range, 20 - 1000 Hz
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: False
N O T I C E
From software version 6.72 onwards, the output frequency of the drive is limited to 590 Hz.
AU275636650261en-000101 / 130R033476 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
