Danfoss VLT AutomationDrive Design Guide

I
AHF,N
Typical Motor Used [kW] Danfoss AHF 005 Danfoss AHF 010 Frequency converter size
10 6 130B2538 130B2539 PK37-P7K5
19 10 - 15 175G6612 175G6634 P11K
26 20 175G6613 175G6635 P15K
35 25 - 30 175G6614 175G6636 P18K - P22K
43 40 175G6615 175G6637 P30K
72 50 - 60 175G6616 175G6638 P37K - P45K
101 75 175G6617 175G6639 P55K
144 100 -125 175G6618 175G6640 P75K - P90K
180 150 175G6619 175G6641 P110
217 200 175G6620 175G6642 P132
289 250 175G6621 175G6643 P160
370 300 175G6690 175G6693 P200
434 350 175G6620 + 175G6620 175G6642 + 175G6642 P250
506 450 175G6620 + 175G6621 175G6642 + 175G6643 P315
578 500 175G6621 + 175G6621 175G6643 + 175G6643 P355
659 550/600 175G6621 + 175G6690 175G6643 + 175G6693 P400
694 600 175G6689 + 175G6690 175G6692 + 175G6693 P450
740 650 175G6690 + 175G6690 175G6693 + 175G6693 P500
Table 5.3 440-480V, 60Hz
IAHF 500V Typical Motor Used [kW] Danfoss AHF 005 Danfoss AHF 010 Frequency converter size
10 0.75 - 7.5 175G6644 175G6656 PK75 - P5K5
19 11 - 15 175G6645 175G6657 P7K5 - P11K
26 18.5 - 22 175G6646 175G6658 P15K - P18K
35 30 175G6647 175G6659 P22K
43 37 175G6648 175G6660 P30K
72 45 - 55 175G6649 175G6661 P37K - P45K
101 75 175G6650 175G6662 P55K
144 90 - 110 175G6651 175G6663 P75K - P90K
180 132 175G6652 175G6664 P110
217 160 175G6653 175G6665 P132
289 200 175G6654 175G6666 P160
324 250 175G6655 175G6667 P200
434 315 175G6653 + 175G6653 175G6665 + 175G6665 P250
506 355 175G6653 + 175G6654 175G6665 + 175G6666 P315
578 400 175G6654 + 175G6654 175G6666 + 175G6666 P355
648 500 175G6655 + 175G6655 175G66967 + 175G6667 P400
Table 5.4 500V, 50 Hz
Matching the frequency converter and filter is pre-calculated based on 400V/480V and on a typical motor load (4 pole) and
160 % torque.
IAHF
525V Typical Motor Used
[kW]
Danfoss AHF 005 Danfoss AHF 010
Frequency converter
size, 525-600 V
Frequency converter size,
525-690 V
10 0.75 - 7.5 175G6644 175G6656 PK75 - P5K5
19 11 - 15 175G6645 175G6657 P7K5 - P11K
26 18.5 - 22 175G6646 175G6658 P15K - P18K
35 30 175G6647 175G6659 P22K
43 37 175G6648 175G6660 P30K
72 30 - 45 175G6649 175G6661 P37K - P45K P37K - P55K
101 55 175G6650 175G6662 P55K - P75K P75K
144 75 - 90 175G6651 175G6663 P90K - P110
180 110 175G6652 175G6664 P132
217 132 175G6653 175G6665 P160
289 160 - 200 175G6654 175G6666 P200 - P250
360 250 175G6652 + 175G6652 175G6664 + 175G6664 P315
397 300 175G6652 + 175G6653 175G66641 + 175G6665 P355
434 315 175G6653 + 175G6653 175G6665 + 175G6665 P400
506 400 175G6653 + 175G6654 175G6665 + 175G6666 P500
578 450 175G6654 + 175G6654 175G6666 + 175G6666 P560
648 500 175G6655 + 175G6655 175G66967 + 175G6667 P630
How to Order FC 300 Design Guide
114 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
55
