8.4.3 Mains Disconnectors, 12-Pulse
Frame size Power Type
380-500V
F9 P250 ABB OETL-NF600A
F9 P315 ABB OETL-NF600A
F9 P355 ABB OETL-NF600A
F9 P400 ABB OETL-NF600A
F11 P450 ABB OETL-NF800A
F11 P500 ABB OETL-NF800A
F11 P560 ABB OETL-NF800A
F11 P630 ABB OT800U21
F13 P710 Merlin Gerin NPJF36000S12AAYP
F13 P800 Merlin Gerin NPJF36000S12AAYP
525-690V
F9 P355 ABB OT400U12-121
F9 P400 ABB OT400U12-121
F9 P500 ABB OT400U12-121
F9 P560 ABB OT400U12-121
F11 P630 ABB OETL-NF600A
F11 P710 ABB OETL-NF600A
F11 P800 ABB OT800U21
F13 P900 ABB OT800U21
F13 P1M0 Merlin Gerin NPJF36000S12AAYP
F13 P1M2 Merlin Gerin NPJF36000S12AAYP
8.4.4 F-Frame Mains Contactors
Frame size Power & Voltage Type
F3 P450-P500 380-500V & P630-P800 525-690V Eaton XTCE650N22A
F3 P560 380-500V Eaton XTCE820N22A
F3 P630380-500V Eaton XTCEC14P22B
F4 P900 525-690V Eaton XTCE820N22A
F4 P710-P800 380-500V & P1M2 525-690V Eaton XTCEC14P22B
WARNING
Customer supplied 230V supply required for Mains
Contactors.
Electrical Installation FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 205
8 8

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
