Danfoss VLT AutomationDrive Design Guide

130BB017.10
1
2
3
4
5
6
7
8
9
10
Illustration 8.32 Compact IP00 (Chassis), frame size D3
1
2
3
4
5
6
7
8
9
10
130BB018.10
FASTEMER TORQUE: M10 19 NM (14 FT-LB)
FASTEMER TORQUE: M8 9.6 NM (7 FT-LB)
R/L1 91
-DC 88
+DC 89
FASTEMER TORQUE: M8 9.6 NM (7 FT-LB)
FASTEMER TORQUE: M10 19 NM (14 FT-LB)
R 81
+DR 82
U/T1 96
V/T2 97
W/T3 98
S/L2 92
T/L3 93
Illustration 8.33 Compact IP00 (Chassis) with disconnect, fuse
and RFI filter, frame size D4
1)
AUX Relay 5) Brake
01 02 03 -R +R
04 05 06 81 82
2) Temp Switch 6) SMPS Fuse (see fuse tables for part number)
106 104 105 7) AUX Fan
3) Line 100 101 102 103
R S T L1 L2 L1 L2
91 92 93 8) Fan Fuse (see fuse tables for part number)
L1 L2 L3 9) Mains ground
4) Load sharing 10) Motor
-DC +DC U V W
88 89 96 97 98
T1 T2 T3
Electrical Installation FC 300 Design Guide
172 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
88
