Danfoss VLT AutomationDrive

Enclosure FC 300 Power Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Max trip level
Size [kW] Moeller [A]
A2 0-75-4.0 gG-10 gG-25 PKZM0-25 25
A3 5.5-7.5 gG-10 (5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B3 11-15 gG-25 (11)
gG-32 (15)
gG-63 PKZM4-50 50
B4 18.5-30 gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-125 NZMB1-A100 100
C3 37-45 gG-63 (37)
gG-100 (45)
gG-150 NZMB2-A200 150
C4 55-75 aR-160 (55)
aR-200 (75)
aR-250 NZMB2-A250 250
A5 0.75-7.5 gG-10 (0.75-5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B1 11-18 gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-80 PKZM4-63 63
B2 22-30 gG-50 (22)
gG-63 (30)
gG-100 NZMB1-A100 100
C1 37-55 gG-63 (37)
gG-100 (45)
aR-160 (55)
gG-160 (37-45)
aR-250 (55)
NZMB2-A200 160
C2 75 aR-200 (75) aR-250 NZMB2-A250 250
Table 8.4 525-600V, Frame Sizes A, B, and C
Enclosure
FC 300 Power Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Max trip level
Size [kW] Moeller [A]
B2 11
15
18
22
gG-25 (11)
gG-32 (15)
gG-32 (18)
gG-40 (22)
gG-63 - -
C2 30
37
45
55
75
gG-63 (30)
gG-63 (37)
gG-80 (45)
gG-100 (55)
gG-125 (75)
gG-80 (30)
gG-100 (37)
gG-125 (45)
gG-160 (55-75)
- -
D 37-315
gG-125 (37)
gG-160 (45)
gG-200 (55-75)
aR-250 (90)
aR-315 (110)
aR-350 (132-160)
aR-400 (200)
aR-500 (250)
aR-550 (315)
gG-125 (37)
gG-160 (45)
gG-200 (55-75)
aR-250 (90)
aR-315 (110)
aR-350 (132-160)
aR-400 (200)
aR-500 (250)
aR-550 (315)
- -
E 355-560
aR-700 (355-400)
aR-900 (500-560)
aR-700 (355-400)
aR-900 (500-560)
- -
F 630-1200
aR-1600 (630-900)
aR-2000 (1000)
aR-2500 (1200)
aR-1600 (630-900)
aR-2000 (1000)
aR-2500 (1200)
- -
Table 8.5 525-690V, Frame Sizes B, C, D, E, and F
