Mains Supply 6 x 380 - 500V AC, 12-Pulse
FC 302 P250 P315 P355 P400
High/ Normal Load* HO NO HO NO HO NO HO NO
Typical Shaft output at 400V [kW] 250 315 315 355 355 400 400 450
Typical Shaft output at 460V [HP]
350 450 450 500 500 600 550 600
Typical Shaft output at 500V [kW] 315 355 355 400 400 500 500 530
Enclosure IP21 F8/F9 F8/F9 F8/F9 F8/F9
Enclosure IP54 F8/F9 F8/F9 F8/F9 F8/F9
Output current
Continuous
(at 400V) [A]
480 600 600 658 658 745 695 800
Intermittent (60 sec overload)
(at 400V) [A]
720 660 900 724 987 820 1043 880
Continuous
(at 460/ 500V) [A]
443 540 540 590 590 678 678 730
Intermittent (60 sec overload)
(at 460/ 500V) [A]
665 594 810 649 885 746 1017 803
Continuous KVA
(at 400V) [KVA]
333 416 416 456 456 516 482 554
Continuous KVA
(at 460V) [KVA]
353 430 430 470 470 540 540 582
Continuous KVA
(at 500V) [KVA]
384 468 468 511 511 587 587 632
Max. input current
Continuous
(at 400V ) [A]
472 590 590 647 647 733 684 787
Continuous
(at 460/ 500V) [A]
436 531 531 580 580 667 667 718
Max. cable size, mains [mm
2
(AWG
2)
)]
4x90 (3/0) 4x90 (3/0) 4x240 (500 mcm) 4x240 (500 mcm)
Max. cable size, motor [mm
2
(AWG
2)
)]
4x240
(4x500 mcm)
4x240
(4x500 mcm)
4x240
(4x500 mcm)
4x240
(4x500 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
Max. external mains fuses [A]
1
700
Estimated power loss
at 400V [W]
4)
5164 6790 6960 7701 7691 8879 8178 9670
Estimated power loss
at 460V [W]
4822 6082 6345 6953 6944 8089 8085 8803
Weight,enclosure IP21, IP 54 [kg] 440/656
Efficiency
4)
0.98
Output frequency 0 - 600Hz
Heatsink overtemp. trip 95°C
Power card ambient trip 75°C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
