Danfoss VLT AutomationDrive Design Guide

Mains Supply 3 x 525 - 600V AC
FC 302 P37K P45K P55K P75K
High/
Normal
Load*
HO NO HO NO HO NO HO NO
Typical Shaft Output [kW] 37 45 45 55 55 75 75 90
Enclosure IP21, 55, 66 C1 C1 C1 C2 C2
Enclosure IP20 C3 C3 C3 C4 C4
Output current
Continuous
(3 x 525-550V) [A]
54 65 65 87 87 105 105 137
Intermittent
(3 x 525-550V) [A]
81 72 98 96 131 116 158 151
Continuous
(3 x 525-600V) [A]
52 62 62 83 83 100 100 131
Intermittent
(3 x 525-600V) [A]
78 68 93 91 125 110 150 144
Continuous kVA (550V AC) [kVA] 51.4 61.9 61.9 82.9 82.9 100.0 100.0 130.5
Continuous kVA (575V AC) [kVA] 51.8 61.7 61.7 82.7 82.7 99.6 99.6 130.5
Max. input current
Continuous
at 550V [A]
49 59 59 78.9 78.9 95.3 95.3 124.3
Intermittent
at 550V [A]
74 65 89 87 118 105 143 137
Continuous
at 575V [A]
47 56 56 75 75 91 91 119
Intermittent
at 575V [A]
70 62 85 83 113 100 137 131
Additional specifications
IP20 max. cable cross-section
5)
(mains and motor)
50 (1) 150 (300MCM)
IP20 max. cable cross-section
5)
(brake and load sharing)
50 (1) 95 (4/0)
IP21, 55, 66 max. cable cross-
section
5)
(mains, motor) [mm
2
(AWG)]
2)
50 (1) 150 (300MCM)
IP21, 55, 66 max. cable cross-
section
5)
(brake, load sharing)
[mm
2
(AWG)]
2)
50 (1) 95 (4/0)
Max cable size with mains
disconnect [mm
2
(AWG)]
2)
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350MCM, 300MCM, 4/0)
Estimated power loss
at rated max. load [W]
4)
850 1100 1400 1500
Weight,
enclosure IP20 [kg]
35 35 50 50
Weight,
enclosure IP21, 55 [kg]
45 45 65 65
Efficiency
4)
0.98 0.98 0.98 0.98
FC 300 Selection FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 73
4 4
