Normal overload 150% for 1 minute
Frequency converter
Typical shaft output [kW]
P5K5
5.5
P7K5
7.5
P11K
11
P15K
15
P18K
18.5
P22K
22
Typical shaft output [hp] 7.5 10 15 20 25 30
Enclosure protection rating IP20 M3 M3 M4 M4 M5 M5
Output current
Continuous (3x380–440 V) [A] 12.0 15.5 23.0 31.0 37.0 43.0
Intermittent (3x380–440 V) [A] 18.0 23.5 34.5 46.5 55.5 64.5
Continuous (3x440–480 V) [A] 11.0 14.0 21.0 27.0 34.0 40.0
Intermittent (3x440–480 V) [A] 16.5 21.3 31.5 40.5 51.0 60.0
Maximum cable size:
(Mains, motor) [mm
2
/AWG]
4/10 16/6
Maximum input current
Continuous (3x380–440 V) [A] 19.2 24.8 33.0 42.0 34.7 41.2
Intermittent (3x380–440 V) [A] 27.4 36.3 47.5 60.0 49.0 57.6
Continuous (3x440–480 V) [A] 16.6 21.4 29.0 36.0 31.5 37.5
Intermittent (3x440–480 V) [A] 23.6 30.1 41.0 52.0 44.0 53.0
Maximum mains fuses [A] See chapter 1.3.3 Fuses
Environment
Estimated power loss [W]
Best case/typical
1)
131.0/
166.8
175.0/
217.5
290.0/
342.0
387.0/
454.0
395.0/
428.0
467.0/
520.0
Weight enclosure IP20 [kg] 3.0 3.0
Eciency [%]
Best case/typical
2)
98.0/
97.5
98.0/
97.5
97.8/
97.4
97.7/
97.4
98.1/
98.0
98.1/
97.9
Table 1.9 Mains Supply 3x380–480 V AC
1) Applies for dimensioning of frequency converter cooling. If the switching frequency is higher than the default setting, the power losses may
increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to www.danfoss.com/
vltenergyeciency.
2) Eciency measured at nominal current. For energy eciency class, see chapter 1.8.1 Surroundings. For part load losses, see www.danfoss.com/
vltenergyeciency.
