Danfoss VLT Micro Drive FC 51 Quick Guide

1.8 General Technical Data
Protection and features
•
Electronic motor thermal protection against overload.
•
Temperature monitoring of the heat sink ensures that the frequency converter trips if there is overtemperature.
•
The frequency converter is protected against short circuits between motor terminals U, V, W.
•
When a motor phase is missing, the frequency converter trips and issues an alarm.
•
When a mains phase is missing, the frequency converter trips or issues a warning (depending on the load).
•
Monitoring of the DC-link voltage ensures that the frequency converter trips when the DC-link voltage is too low
or too high.
•
The frequency converter is protected against ground faults on motor terminals U, V, W.
Mains supply (L1/L, L2, L3/N)
Supply voltage 200–240 V ±10%
Supply voltage 380–480 V ±10%
Supply frequency 50/60 Hz
Maximum imbalance temporary between mains phases 3.0% of rated supply voltage
True power factor ≥0.4 nominal at rated load
Displacement power factor (cosφ) near unity (>0.98)
Switching on input supply L1/L, L2, L3/N (power-ups) Maximum 2 times/minute
Environment according to EN60664-1 Overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100000 RMS symmetrical Amperes, 240/480 V
maximum.
Motor output (U, V, W)
Output voltage 0–100% of supply voltage
Output frequency 0–200 Hz (VVC
+
), 0–400 Hz (u/f)
Switching on output Unlimited
Ramp times 0.05–3600 s
Cable length and cross-section
Maximum motor cable length, shielded/armored (EMC-correct installation) 15 m (49 ft)
Maximum motor cable length, unshielded/unarmored 50 m (164 ft)
Maximum cross-section to motor, mains
1)
Connection to load sharing/brake (M1, M2, M3) 6.3 mm insulated Faston plugs
Maximum cross-section to load sharing/brake (M4, M5) 16 mm
2
/6 AWG
Maximum cross-section to control terminals, rigid wire 1.5 mm
2
/16 AWG (2x0.75 mm
2
)
Maximum cross-section to control terminals, exible cable 1 mm
2
/18 AWG
Maximum cross-section to control terminals, cable with enclosed core 0.5 mm
2
/20 AWG
Minimum cross-section to control terminals 0.25 mm
2
(24 AWG)
1) See chapter 1.7 Specications for more information.
Digital inputs (pulse/encoder inputs)
Programmable digital inputs (pulse/encoder) 5 (1)
Terminal number 18, 19, 27, 29, 33
Logic PNP or NPN
Voltage level 0–24 V DC
Voltage level, logic 0 PNP <5 V DC
Voltage level, logic 1 PNP >10 V DC
Voltage level, logic 0 NPN >19 V DC
Voltage level, logic 1 NPN <14 V DC
Maximum voltage on input 28 V DC
Input resistance, R
i
Approximately 4000 Ω
Maximum pulse frequency at terminal 33 5000 Hz
Quick Guide
VLT
®
Micro Drive FC 51
26 Danfoss A/S © 05/2016 All rights reserved. MG02BB4P
11

Danfoss VLT Micro Drive FC 51 Specifications

General

Enclosure	IP20
Output Voltage	0-100% of supply voltage
Altitude	Up to 1000 m without derating
Power Range	0.18-22 kW
Control Method	V/f
Communication	Modbus RTU
Protection Features	Over-voltage, under-voltage, over-current, over-temperature
Ambient Temperature	-10°C to 50°C
Storage Temperature	-25°C to 65°C
Relative Humidity	5-95% (non-condensing)
Input Voltage	200-240 V, 380-480 V
Braking Function	Integrated braking chopper (optional)
