Page #8 background imageLoading...
Page #8 background image
1 Quick Guide
1.1 Safety
WARNING
HIGH VOLTAGE
Frequency converters contain high voltage when
connected to AC mains input, DC supply, or load sharing.
Failure to perform installation, start-up, and maintenance
by qualied personnel can result in death or serious
injury.
Only qualied personnel must perform instal-
lation, start-up, and maintenance.
WARNING
UNINTENDED START
When the frequency converter is connected to AC mains,
the motor may start at any time, causing risk of death,
serious injury, equipment, or property damage. The
motor can start by means of an external switch, a
eldbus command, an input reference signal from the
LCP or LOP, or after a cleared fault condition.
Disconnect the frequency converter from mains
whenever personal safety considerations make
it necessary to avoid unintended motor start.
Press [O/Reset] on the LCP before
programming parameters.
The frequency converter, motor, and any driven
equipment must be in operational readiness
when the frequency converter is connected to
AC mains.
NOTICE
The [O/Reset] key is not a safety switch. It does not
disconnect the frequency converter from mains.
WARNING
DISCHARGE TIME
The frequency converter contains DC-link capacitors,
which can remain charged even when the frequency
converter is not powered. High voltage can be present
even when the warning LED indicator lights are o.
Failure to wait the specied time after power has been
removed before performing service or repair work can
result in death or serious injury.
Stop the motor.
Disconnect AC mains and remote DC-link power
supplies, including battery back-ups, UPS, and
DC-link connections to other frequency
converters.
Disconnect or lock PM motor.
Wait for the capacitors to discharge fully. The
minimum duration of waiting time is specied
in Table 1.1.
Before performing any service or repair work,
use an appropriate voltage measuring device to
make sure that the capacitors are fully
discharged.
Size Minimum waiting time (minutes)
M1, M2, and M3 4
M4 and M5 15
Table 1.1 Discharge Time
Leakage current (>3.5 mA)
Follow national and local codes regarding protective
earthing of equipment with a leakage current >3,5 mA.
Frequency converter technology implies high frequency
switching at high power. This generates a leakage current
in the ground connection. A fault current in the frequency
converter at the output power terminals might contain a
DC component, which can charge the lter capacitors and
cause a transient ground current. The ground leakage
current depends on various system congurations
including RFI ltering, screened motor cables, and
frequency converter power.
EN/IEC61800-5-1 (Power Drive System Product Standard)
requires special care if the leakage current exceeds 3.5 mA.
Reinforce Grounding in 1 of the following ways:
Grounding wire of at least 10 mm
2
.
2 separate ground wires both complying with the
dimensioning rules.
Quick Guide
VLT
®
Micro Drive FC 51
6 Danfoss A/S © 05/2016 All rights reserved. MG02BB4P
