DS8100
44
4
Conveyor
direction
Figure 52 - Code reading and assignment
Conveyor
direction
Tracking Area
TX
line
End of the
Tracking Area
PS
line
PS Photocell or
equivalent signal
Reading Area
Figure 53 - PackTrack
system layout
