DS8100 model
Serial Interface Bus Interface
Standard Oscillating Mirror Standard Oscillating Mirror
ELECTRICAL FEATURES (see note 1)
Supply voltage 20 to 30 Vdc
Operating current 1.3 - 0.9 A
Power consumption 30 W
Serial Interfaces
Main RS232
RS485 Lonworks network
20 mA C.L.
Auxiliary RS232, RS485
Baud Rates 1200 to 57600 1.25 Mb/s
Inputs
Command inputs
(NPN or PNP)
Presence sensor (optocoupled)
Encoder input (optocoupled)
Auxiliary input (optocoupled)
Outputs
Outputs No Read (optocoupled)
(open emitter or collector) Right Code (optocoupled)
OPTICAL FEATURES (see note 1)
Light source up to 4 semiconductor laser diodes
Wave length 630 to 680 nm
Safety class Class 2 - IEC 825-1; Class II - CDRH
Light receiver Avalanche photodiode
READING FEATURES
Scan rate
≤ 1000 scan/s ≤ 1200 scan/s ≤ 1000 scan/s ≤ 1200 scan/s
Maximum resolution
Max. reading distance
Max. reading width
Max. depth of field
Aperture angle
(see reading diagrams in par. 4.4)
USER INTERFACE
LCD Display:
2 lines, 20 characters
4 key keypad
LED indicators Power ON, Ext Trig, Encoder,
Good Read, TX Data,
User Defined
Power ON, Ext Trig, Encoder,
Good Read, TX Data, Network.
Note 1: The values given are typical at 25 °C ambient temperature (if not otherwise indicated)
