DS8100
50
6
DS8100 model
Serial Interface Bus Interface
SOFTWARE FEATURES
Readable code symbologies
• Interleaved 2/5 • Code 128
• Code 39 Standard • EAN128
• EAN/UPC
• Code 93
• Codabar
Code selection
Up to 5 code symbologies during one reading phase
Decoding safety
Several good reads of the same code can be enabled
separately for each code
Headers and Terminators
Transmitted messages can be personalized using up to 4
headers and 4 terminators
Operating modes
On Line
Serial On Line Depending on SC8000
Automatic
Test
Pack Track™
Configuration modes
WinHost utility program
SC8000
Keyboard Mode:
using the built-in keypad
Host Mode:
receiving commands from the
serial port
Parameter storage
Non-volatile internal EEPROM
DS8100 model
Standard Oscillating Mirror
ENVIRONMENTAL FEATURES
Operating temperature 0° to +40 °C (+32° to +104 °F)
Storage temperature -20° to +70 °C (-4° to +158 °F)
Humidity 90% non condensing
Vibration resistance
IEC 68-2-6 test FC
2 hours on each axis
1.5 mm; 10 to 55 Hz; 1.5 mm @ 5 to 9.1 Hz
0.5 G @ 9.1 to 150 Hz
Shock resistance
IEC 68-2-27 test EA 30 G; 11 ms 15 G; 11 ms
3 shocks on each axis
Protection Class IP64 (sealed connectors required)
PHYSICAL FEATURES
Mechanical dimensions 215.5 x 170.5 x 126.5 mm
(8.48 x 6.71 x 4.98 in)
280 x 254 x 195 mm
(11.03 x 10 x 7.68 in)
Weight 5 kg (176.3 oz) 6.4 kg (225.7 oz)
