CBX ELECTRICAL CONNECTIONS
33
3
OUTPUT 1 and 2 CONNECTIONS USING EXTERNAL POWER
Output Device
Power Reference
Output
Signal
Output Device
Figure 38 - Open Emitter Output Using External Power
Output Device
Ground Reference
Output
Signal
Output Device
Figure 39 - Open Collector Output Using External Power
OUTPUT 3 CONNECTIONS USING DS8100A POWER (CBX500 Only)
Power to
Output Device
Output Output Device
Signal Reference
Output Device
Figure 40 - Output 3 Using DS8100A Power
Power to
Output Device
Output Output Device
Signal Ground Reference
Output Device
Figure 41 - Output 3 Using DS8100A Power
