Datalogic DS8100A User Manual

SOFTWARE CONFIGURATION
77
8
Parameter
Default Setting
Reading System Layout
Device Assignment
Alone
Modify&Backup Lon Slave Configuration
Disabled (unchecked)
Enable A.S.R.
Disabled (unchecked)
Reading Parameters
Beam Shutter
Disabled
Overflow Start Ratio
5
Overflow Stop Ratio
5
Reading Mode
Reconstruction
Reading Condition
Standard
Reconstruction Parameters
Enabled Stacked Code
Disabled (unchecked)
Extended
Min Match
0
Position Tolerance
50
Duration Tolerance
50
Min Start/Stop Number
2
Inter Char Gap
8
Addon Start/Stop Overflow Ratio
2
Max distance between EAN/UPC
and Addon (in modules)
20
Scan Line Amplitude
Amplitude Settings Enable
Disabled (unchecked)
PackTrack Calibration
Direction
0 (Forward)
PS Offset
0
Data Communication Settings
Host Application Protocol Type
Standard
Data Format
Header Tx Start
With Data
Termination After No Read Message
Enabled (checked)
Message Tx Selection
On Decoding
Format Type
Standard
Max. Tx Delay After Phase Off
Disabled
Code Identifier
Disabled
Standard Parameters
Header String
<STX>
Code Position Tx
Disabled (unchecked)
Code Direction Identifier Enable
Disabled (unchecked)
Termination String
<CR><LF>
Data Packet Separators
<CR><LF>
Code Field Length Setting
Variable Length
Main Serial Port
Main Serial Interface Dedicated to ID-NET
Disabled (unchecked)
Data Tx
Enabled (checked)
Heartbeat
Disable
