DS8100A REFERENCE MANUAL
78
8
Parameter
Default Setting
Main Serial Port Parameters
Main Port Communication Mode
Standard
Main Port Electrical Interface
RS232
Handshake
None
Baud Rate
9600
Parity
None
Data Bits
8
Stop Bits
1
Auxiliary Serial Port
Search for CBX BM100 at Device Startup
Enabled (checked)
Data Tx
Enabled (checked)
Heartbeat
Disable
Pass Through
Disabled (unchecked)
Auxiliary Serial Port Parameters
Baud Rate
115200
Parity
None
Data Bits
8
Stop Bits
1
Digital I/O Setting
Digital Input Lines Setting
Debouncing For Input 1, 3 and 4
5ms
Debouncing For Input 2
500 µs
Input 1 Active Level Overridden by Op. Mode
Active Closed
Input 2 Active Level Overridden by Op. Mode
Active Closed
Input 3 Active Level Overridden by Op. Mode
Active Closed
Input 4 Active Level Overridden by Op. Mode
Active Closed
Output 1
Line State
Normally Open
Activation Event
Complete Read
Alternative Activation Event
Wrong
Deactivation Event
Timeout
Alternative Deactivation Event
None
Activate on any Diagnostic Error
Disabled (unchecked)
Deactivate when all Diagnostic Errors
Recovered
Disabled (unchecked)
Deactivation Timeout (ms)
50
Output 2
Line State
Normally Open
Activation Event
No Read
Alternative Activation Event
Partial Read
Deactivation Event
Timeout
Alternative Deactivation Event
None
Activate on any Diagnostic Error
Disabled (unchecked)
Deactivate when all Diagnostic Errors
Recovered
Disabled (unchecked)
Deactivation Timeout (ms)
50
