6-68 Magellan
®
8100/8100Ω and 8200/8200Ω Scanner
RS-232 Features
RS-232 Baud Rate
This feature selects the baud rate required for sending and receiving data.
To specify the RS-232 Baud Rate:
1. Scan the SWITCH bar code.
2. Scan the desired baud rate from the bar codes below and on the
immediately following pages. You’ll need to cover any unused bar
codes on this and the facing page to ensure that the scanner reads
only the bar code you intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
RS-232 BAUD RATE = 1200
RS-232 BAUD RATE = 2400
NOTE
Single cable interfaces are limited to Baud Rate selections up to 19200. They
cannot communicate at Baud Rates of 38400 and up.
To Next Page
