6-222 Magellan
®
8100/8100Ω and 8200/8200Ω Scanner
I 2 of 5 Stitching
Enables/disables stitching for I 2 of 5 labels. When parts of an I 2 of 5 bar
code are presented to the scanner with this feature enabled, the bar code
parts will be assembled by the scanner’s software, and the data will be
decoded if all bar code proofing requirements are met.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan your selection from the bar codes below. You’ll need to cover
any unused bar codes on this and the facing page to ensure that
the scanner reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
I 2 OF 5 STITCHING = DISABLE
I 2 OF 5 STITCHING = ENABLE
NOTE
I 2 of 5 Stitching operates using fixed lengths ONLY. I 2 of 5 Fixed Length 1
and/or I 2 of 5 Fixed Length 2 must be properly configured for stitching to
work.
