B-8 Magellan

8100/8100Ω and 8200/8200Ω Scanner

Power Cable

Connector Hardware

6 pin Molex

Cable Pinout

Remote Display

Connector Hardware

4 pin SDL

Cable Pinout

Table B-7

PIN # FUNCTION DESCRIPTION

1 EARTH GND Earth Ground

2 SIGNAL GND Signal Ground

3 +5V IN +5V in

4 N/C No Connection

5 N/C No Connection

6 +12V IN +12V in

Table B-8

PIN # FUNCTION DESCRIPTION

1 +12V OUT +12V out

2 LINE_A_DSPLY LINE A Display

3 LINE_B_DSPLY LINE B Display

4 GND Ground
