Product Reference Guide 6-235
Codabar Fixed Length 1
This feature specifies Codabar first fixed length.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code, SET CODABAR FIXED LENGTH 1 below.
You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend
to scan.
3. Scan the appropriate digits from the keypad in Appendix C that
represent the desired fixed label length. The selectable range for
this option is 03 to 50. Pad all single digit numbers with a leading
zero to yield a two-digit entry (03-50).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET CODABAR FIXED LENGTH 1
NOTE
Length in this case includes start, stop or check and data characters, but
does not include full ASCII shift characters.
This feature applies when Codabar Length Control is set to fixed-
length decoding.
Decodable length is four when the optional check character is present.
