4-4 Magellan
®
8100/8100Ω and 8200/8200Ω Scanner
Table 4-1. Error Codes and Corrective Action
Error
Code
Probable Cause Corrective Action
0
Blinking
Configuration
No POS interface has been selected (Null interface). See the topic,
Interface Type, in Section 6 to select the required interface using
programming bar codes.
1 Configuration Error
See Section 6, Programming, for details about configuring the scan-
ner using programming bar codes.
2 Digital Board Unplug unit and call technical support personnel.
3 Motor Unplug unit and call technical support personnel.
4 Laser Call technical support personnel.
5
Laser
Call technical support personnel.
6 Digital Board Unplug unit and call technical support personnel.
7Scale
See the topic Scale Error Reporting in this section for problem
identification and corrective actions.
8 Remote Display
Connect the Remote Display. If necessary, replace display or cable.
Alternatively, you can disable the Remote Display using the program-
ming procedures described in Section 6.
A Button Module Call technical support personnel
C Scale Calibration Proceed to Section 5, Calibration
Decimal
Point
3.3 V Present If not lit, call technical support personnel
