Enter/Exit Programming Mode
Product Reference Guide
261
ACTION CONFIGURATION FOR FUNCTION KEYS
Configure actions (up to three for 4K model when configured with "Function
Keys Action Select Mode") for the function keys
Configure Actions for F1
DEFAULT
F1 No Actions Configured
Configure Actions for F1
To configure this feature, sca
n the ENTER/EXIT PROGRAM-
MING MODE bar code above, then the bar code for the Func-
tion Key you want to program. Next scan 4 digits from the
Al
phanumeric characters in
Appendix D, Keypad
.
The first digit must be 0, the second is used by 4K and 16K
model, the remaining third and fourth are used only by 4K
model. Second, third and fourth digit must be configured
according to the CMD_ID numbers in
Table 30 on
page 260
. Confirm the inserted value by scanning the
ENTER/EXIT bar code.
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
To Next Page
