References
308
PowerScan™ PD9130/PBT9100/PM9100
Scanning Features
Scan Mode
This mode is associated with typical handheld reader operation. Selects the
scan operating mode for the reader. The following selections are valid for all
models:
Trigger Single:
When the trigger is pulled, scanning is activated until one of
the following occurs:
- a label has been read
- the trigger is released
Trigger Hold Multiple:
When the trigger is pulled, scanning starts and the
product scans until the trigger is released. Reading a label does not disable
scanning.
Double Read Timeout prevents undesired multiple reads of the
same label while in this mode.
Trigger Pulse Multiple:
When the trigger is pulled, continuous scanning is acti-
vated until the trigger has been released and pulled again. Double Read
Timeout prevents undesired multiple reads of the same label while in this
mode.
Flashing:
The reader flashes on and off regardless of the trigger status. When
Flash is ON the scanner reads continuously; when Flash is OFF scanning is
deactivated.
Always On:
No trigger pull is required to read a bar code. Scanning is contin-
ually on. If the trigger is pulled, the reader acts as if it is in Trigger Single
Mode.
Double Read Timeout prevents undesired multiple reads of the same
label while in this mode.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic PowerScan PBT9100 and is the answer not in the manual?

Datalogic PowerScan PBT9100 Specifications

General IconGeneral
Harmonized System (HS) code84716070
TypeHandheld bar code reader
Sensor typeLED
Scanner type1D
Yaw reading angle-70 - 70 °
Scanner resolution0.13 mm
Tilt reading angle-45 - 45 °
Pitch reading angle-75 - 75 °
Linear (1D) barcodes supportedCodabar, Code 11, Code 128, Code 32, Code 39, Code 39 (ASCII), Code 93, EAN 128, GS1 DataBar, IATA, ISBN, Industrial 2 of 5, Interleaved 2 of 5, MSI, Plessey, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported-
Wireless range100 m
Bluetooth version3.0
Operating frequency2.4-2480 MHz
Standard interfacesBluetooth, RS-232
Connectivity technologyWireless
CertificationIEC 62471
Product colorBlack, Yellow
LED indicatorsYes
International Protection (IP) codeIP65
Battery life10 h
Battery typeBuilt-in battery
Charging time4.5 h
Input voltage10-30 V
Battery capacity3350 mAh
Power consumption500 mA
Power source typeBattery
AC adapter output voltage110 V
Number of reads per charge60000
Power consumption (typical)10 W
Cables includedDC, RS-232
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Warranty period3 year(s)
Sustainability certificatesRoHS
Weight and Dimensions IconWeight and Dimensions
Depth74 mm
Width110 mm
Height240 mm
Weight405 g
Base dimensions212 x 110 x 74 mm
