References
302
PowerScan™ PD9130/PBT9100/PM9100
Label ID
A Label ID is a customizable code of up to three ASCII characters (each can
be one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It
can be appended previous to or following the transmitted bar code data
depending upon how this option is enabled. This feature provides options
for configuring custom Label IDs as a pre-loaded set (see "Label ID: Pre-
loaded Sets" below) or individually per symbology (see "Label ID: Set Individ-
ually Per Symbology" on
page 304). If you wish to program the reader to
always include an industry standard label identifier for ALL symbology types,
se
e "Global AIM ID" on
page 51.
Label ID: Pre-loaded Sets
The reader supports two pre-loaded sets of Label IDs. Table 41 shows the
USA and the EU sets.
CAUTION
When changing from one Label ID set to another, all other reader configuration
settings, including the host interface type, will be erased and set to the stan-
dard factory defaults. Any custom configuratio
n or custom defaults will be lost.
Table 41
.
Label ID Pre-loaded Sets
Symbology
USA Label ID set EU Label ID set
Default
Character
Default
ASCII
Default
Character
Default
ASCII
CODABAR
% 250000 R 520000
CODE11
CE 434500 b 620000
CODE128
# 230000 T 540000
CODE32
A 410000 X 580000
CODE39
* 2A0000 V 560000
CODE39 CIP
Y 590000 Y 590000
CODE93
& 260000 U 550000
DATABAR 14
R4 523400 u 750000
DATABAR 14 COMPOSITE
R4 523400 c 523400
DATABAR EXPANDED
RX 525800 t 740000
DATABAR EXPANDED COMPOSITE
RX 525800 d 525800
DATABAR LIMITED
RL 524C00 v 760000
DATABAR LIMITED COMPOSITE
RL 524C00 i 524C00
EAN128
000000 k 6B0000
EAN128 COMPOSITE
000000 $E 244500
EAN13
F 460000 B 420000
EAN13 P2
F 460000 L 4C0000
To Next Page
