PowerScan™ PD9130/PBT9100/PM9100

Bluetooth-Only Features

Bluetooth Pin Code

This option specifies the 4-character or 16-character pin code to be used

for authentication of the Bluetooth link. To set the pin code:

1. Sc

an the ENTER/EXIT PROGRAMMING MODE bar code to enter Program-

ming Mode, then enable Bluetooth Security Mode on page 235.

2. S

pecify the desired pin code length (4 or 16) by scanning the appropri-

ate bar code in Select PIN Code Length on page 235.

3. Determine the desired characters. For example, D254 or

OR12345678135M.

4. Convert the characters to hexadecimal using the ASC

II Chart on the

inside back cover of this manual.

5. Go to page 235 and Scan the bar code: SET 4 CHAR PIN CODE or SET

16-CHAR PIN CODE.

6. Scan the appropriate alphanumeric characters from the keypad in

Appendix D, Keypad, representing the hexadecimal entries determined

in the steps above. You will hear a two-beep indication after the last

haracter.

If you make a mistake before the last character, scan the CANCEL bar code to abort

and not save the entry string. You can then start again at the beginning.

7. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Program-

ming Mode.

Changing the pin code setting will unlink the devices. If the Automatic Configura-

tion Update is set to the default enabled setti

ng, the devices must only be relinked.

If the Automatic Configuration Update is set to the disabled setting, the Pin Code

setting must also be updated in the Base Station using Aladdin. After the Base

Station has been updated, the devices must be relinked.

Table 47. Bluetooth Pin Code Setting Examples

STEP ACTION EXAMPLES

1 Desired Setting

D254 STOR12345678135M

Convert the characters

to hexadec

imal

44 32 35 34 53 54 4F 52 31 32 33 34 35 36 37 38 31 33 35 4D

3 Scan ENTER/EXIT PROGRAMMING MODE

4 Scan SET Bluetooth PIN CODE

Scan 8 or 32

Alp

hanumeric

Characters From

Appendix D, Keypad

44323534 53544F5231323334353637383133354D

6 Scan ENTER/EXIT PROGRAMMING MODE

Datalogic PowerScan PBT9100 Specifications

General

Harmonized System (HS) code	84716070
Type	Handheld bar code reader
Sensor type	LED
Scanner type	1D
Yaw reading angle	-70 - 70 °
Scanner resolution	0.13 mm
Tilt reading angle	-45 - 45 °
Pitch reading angle	-75 - 75 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 39 (ASCII), Code 93, EAN 128, GS1 DataBar, IATA, ISBN, Industrial 2 of 5, Interleaved 2 of 5, MSI, Plessey, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	-
Wireless range	100 m
Bluetooth version	3.0
Operating frequency	2.4-2480 MHz
Standard interfaces	Bluetooth, RS-232
Connectivity technology	Wireless
Certification	IEC 62471
Product color	Black, Yellow
LED indicators	Yes
International Protection (IP) code	IP65
Battery life	10 h
Battery type	Built-in battery
Charging time	4.5 h
Input voltage	10-30 V
Battery capacity	3350 mAh
Power consumption	500 mA
Power source type	Battery
AC adapter output voltage	110 V
Number of reads per charge	60000
Power consumption (typical)	10 W
Cables included	DC, RS-232
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Warranty period	3 year(s)
Sustainability certificates	RoHS
