Product Reference Guide
317
Appendix A
Technical Specifications
The tables that follow contain Physical and Performance Characteristics,
User Environment and Regulatory information.
Table 49 provides Standard
Cable Pinouts.
Table 48. Technical Specifications
Item Description
Physical Characteristics
Dimensions
Height: 212 mm
Length: 110 mm
Width: 74 mm
Weight (without cable)
PD9130: 340g
PM/PBT9100-XX: 405g;
PM9100-DXX, PM9100-DKXX: 435g;
Electrical Characteristics
PD9130 models
Voltage & Current
Input Voltage 4.5 / 30 VDC
Input Current
Operating (typical, scan-
ning)
190 mA @ 4.5 V
170 mA @ 5 V
80 mA @ 12 V
40 mA @ 30 V
Operating (max, reading)
440 mA @ 4.5 V
380 mA @ 5 V
150 mA @ 12 V
75 mA @ 30 V
Idle/Standby (typical)
35 mA @ 4.5 V
30 mA @ 5 V
20 mA @ 12 V
12 mA @ 30 V
