DEFAULT
F2 No Actions Configured
Configure Actions for F2
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code
for
the Function Key you want to program. Next scan
4 digits from the Alphanumeric characters in
Appen-
dix D, Keypad
.
The first digit must be 0, the second is used by 4K and
16K m
odel, the remaining third and fourth are used
only by 4K model. Second, third and fourth digit must
be configured according to the CMD_ID numbers in
Table 30 on page 260
. Confirm the inserted value
by scanning the ENTER/EXIT bar code.
Make a mistake? Scan the CANCEL
bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
Enter/Exit Programming Mode
262
PowerScan™ PD9130/PBT9100/PM9100
Configure Actions for F2
