General| Harmonized System (HS) code | 84716070 |
|---|---|
| Type | Handheld bar code reader |
| Sensor type | LED |
| Scanner type | 1D |
| Yaw reading angle | -70 - 70 ° |
| Scanner resolution | 0.13 mm |
| Tilt reading angle | -45 - 45 ° |
| Pitch reading angle | -75 - 75 ° |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 32, Code 39, Code 39 (ASCII), Code 93, EAN 128, GS1 DataBar, IATA, ISBN, Industrial 2 of 5, Interleaved 2 of 5, MSI, Plessey, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | - |
| Wireless range | 100 m |
| Bluetooth version | 3.0 |
| Operating frequency | 2.4-2480 MHz |
| Standard interfaces | Bluetooth, RS-232 |
| Connectivity technology | Wireless |
| Certification | IEC 62471 |
| Product color | Black, Yellow |
| LED indicators | Yes |
| International Protection (IP) code | IP65 |
| Battery life | 10 h |
| Battery type | Built-in battery |
| Charging time | 4.5 h |
| Input voltage | 10-30 V |
| Battery capacity | 3350 mAh |
| Power consumption | 500 mA |
| Power source type | Battery |
| AC adapter output voltage | 110 V |
| Number of reads per charge | 60000 |
| Power consumption (typical) | 10 W |
| Cables included | DC, RS-232 |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Warranty period | 3 year(s) |
| Sustainability certificates | RoHS |
Weight and Dimensions| Depth | 74 mm |
|---|---|
| Width | 110 mm |
| Height | 240 mm |
| Weight | 405 g |
| Base dimensions | 212 x 110 x 74 mm |
