USB COM PARAMETERS
PRODUCT REFERENCE GUIDE
153
Disable Character
Specifies the value of the host command used to disable the scanner.
ASCII characters or any hex value from 0 to 0xFF can be selected.
To set the value:
1. Determine the desired character or value. A setting of 0xFF indicates the Disable
Character is not used (not available).
2. Use the ASCII Chart on
page 204 to find the hex equivalent for the desired charac-
ter/value.
3. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming
Mode.
4. Scan the bar code: SELECT DISABLE CHARACTER SETTING on
page 8.
5. Scan the appropriate two alphanumeric characters from the keypad in
Appendix D,
that represent the desired character/value determined above. The second charac-
ter will cause a two-beep indication.
6. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming Mode.
This completes the procedure. See the table below for examples of how to set this fea-
ture.
Table 6 -Disable Character Setting Examples
NOTE: Setting to previously defined characters such as XON, XOFF, or host
commands conflicts with normal operation of these characters. 8-bit data
is not recognized when the option "
Data Bits" on page 36 has been set as 7
Data Bits.
STEP
ACTION EXAMPLES
1 Desired character/value
‘d’ ‘}’ ‘D’
Disable Com-
mand
Not Used
2
Hex equivalent from ASCII Chart
on
page 204
0x64 0x7D 0x44 0xFF
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT DISABLE CHARACTER VALUE SETTING
5
Scan three characters from
Appendix D
‘6’ and ‘4’ ‘7’ and ‘D’ ‘4’ and ‘4’ ‘F’ and ‘F’
6 Scan ENTER/EXIT PROGRAMMING MODE
To Next Page
