DECODING CAPABILITIES
LED AND BEEPER INDICATIONS
The imager’s beeper sounds and its illumination flashes or changes color to indicate var-
ious functions or errors on the reader. A “Green Spot” also lights to indicate a good
read. The tables below list these indications.
Table 20LED and Beeper Indications
DECODE CAPABILITY
1D Bar Codes
UPC/EAN/JAN (A, E, 13, 8); UPC/EAN/JAN (including P2 /P5); UPC/EAN/JAN (including;
ISBN / Bookland & ISSN); UPC/EAN Coupons; Code 39 (including full ASCII); Code 39 Triop-
tic; Code39 CIP (French Pharmaceutical); LOGMARS (Code 39 w/ standard check digit
enabled); Danish PPT; Code 32 (Italian Pharmacode 39); Code 128; Code 128 ISBT; Inter-
leaved 2 of 5; Standard 2 of 5; Interleaved 2 of 5 CIP (HR); Industrial 2 of 5; Discrete 2 of 5;
Datalogic 2 of 5 (China Post Code/Chinese 2 of 5); IATA 2of5 Air cargo code; Code 11; Cod-
abar; Codabar (NW7); ABC Codabar; Code 93; MSI; PZN; Plessey; Anker Plessey; Follet 2 of
5; GS1 DataBar Limited; GS1 DataBar Expanded; GS1 DataBar Truncated; DATABAR
Expanded Coupon.
INDICATION LED BEEPER
Power-up
Upper LED flashes/blinks on power-up,
however, this may be too rapid to view.
With a USB interface, the LED blinks
until enumeration with the host is
completed.
Reader beeps four times at highest fre-
quency and volume upon power-up.
Good Read
Upper green LED comes on for pro-
grammed time (default).
LED behavior for this indication is con-
figurable using Aladdin utility.
One beep at current frequency, volume,
mono/bi-tonal setting upon a successful
label scan. It is also possible to upload cus-
tom jingles with Aladdin.
ROM Failure
200 ms on
↔ 200 ms off
Reader sounds one error beep at highest
volume for 200 ms.
Limited Scanning Label
Read
N/A
Reader 'chirps' six times at the highest fre-
quency and current volume.
Reader Disabled
The LED blinks continuously
100 ms on
↔ 900 ms off
N/A
