TECHNICAL SPECIFICATIONS
176 QUICKSCAN™ I QD2200
USER INDICATIONS FOR QD2200
Table 21 User Indications for QD2200
PROGRAMMING MODE
The following indications ONLY occur when the scanner is in Programming Mode.
STATUS 3GL AND GOOD READ LED
Power-up OFF
USB Enumeration Phase
250 ms ON
↔ 250 ms OFF
USB Suspend Depends on Power Cable and specific configurations
Idle OFF
While Reading OFF
Decode Done
Solid ON
Programmable Duration (300ms default)
Reader Disabled (POS)
Communication with host not
established
100 ms ON
↔ 900 ms OFF
Firmware Upgrade
250 ms ON
↔ 250 ms OFF
Enter Service Mode No Effect
Label Programming No Effect
INDICATION DESCRIPTION LED BEEPER
Enter
Programming
Mode
A valid programming label
has been scanned.
LED no effect
Scanner sounds four low fre-
quency beeps.
Rejection of Label Label has been rejected. N/A
Scanner sounds three times at
lowest frequency & current vol-
ume.
Acceptance of
Partial Label
In cases where multiple labels
must be scanned to program
one feature, this indication
acknowledges each portion
as it is successfully scanned.
N/A
Scanner sounds one short beep
at highest frequency & current
volume.
Acceptance of
Programming
Configuration option(s) have
been successfully pro-
grammed via labels and the
scanner has exited Program-
ming Mode.
N/A
Scanner sounds one high fre-
quency beep and four low fre-
quency beeps.
Cancel Item Entry
Cancel label has been
scanned.
N/A
Scanner sounds two times at
low frequency & current volume.
