CONFIGURATION WITH BAR CODES
17
QUICKSCAN™ I QD2200
USB Suspend Mode
This setting enable
s
/disables the ability of USB int
erfaces to en
ter suspend mode.
$CUSSE00
USB Suspend Mode =
D
isable
USB Suspend Mode = Enable
$CUSSE01
