PRODUCT REFERENCE GUIDE
173
APPENDIX A
TECHNICAL SPECIFICATIONS
The table below contains Physical and Performance Characteristics, User Environment
and Regulatory information. Table 34 provides Standard Cable Pinouts.
QD2200 TECHNICAL SPECIFICATIONS
Table 18 QD2200 Technical Specifications
PHYSICAL CHARACTERISTICS
Color
Black
Dimensions
Height 15.6 cm (6.1”)
Length 10.7 cm (4.2”)
Width 6.7 cm (2.6”)
Weight (without cable)
QD2200 approx. 123 g (4.34 oz.)
ELECTRICAL CHARACTERISTICS
Power Supply
QD2220: 5VDC ± 5%
Consumption
Operating (Typical): <500mA @ 5V
Standby/Idle (Typical): <50mA @5V
Max. Scan Rate
400 reads/sec
Reading Indicators
Top illumination, Good Read Spot, Beep
ENVIRONMENTAL CHARACTERISTICS
Operating Temperature
0 °C to + 50 °C (+32° F to +122 °F)
Storage Temperature
-40 °C to + 70 °C (-40 ° F to +158 °F)
Humidity
95% non condensing
Drop Resistance
IEC 68-2-32 Tested
1.5 m (6 ft)
ESD Protection
16 KV
Protection Class
IP52
Ambient Light
120000 Lux
