ENTER/EXIT PROGRAMMING MODE
KEYBOARD INTERFACE
14
QUICKSCAN™ I QD2200
Setting Country Mode (continued)
Vietnamese
$CKBCO17
$CKBCO18
Russian
Arabi
c 10
1
$CKBCO19
$CKBCO1A
Chinese ASCII
Thai-Kedmanee
$CKBCO1B
$CKBCO1C
Albanian
Arabi
c 10
2
$CKBCO1D
43
45
