SOFTWARE CONFIGURATION STRINGS
17
3
SERIAL CONFIGURATION STRINGS
ENTER/EXIT CONFIGURATION COMMANDS
Description Command
Enter Service Mode (configuration) fixed 115200 Baud rate S
Exit Service Mode (configuration) return to programmed Baud rate s
Apply Configuration to RAM (temporary memory) and Exit Service Mode r01
Apply and Save Configuration to FLASH (permanent memory) and Exit Service Mode Ar
NOTE
To configure the reader using configuration strings, you must enter Service
Mode which automatically sets the reader communication to 115200
baudrate. You must therefore set the host accordingly for RS232
communications. Upon exiting Service Mode, the programmed baud rate
will be restored.
CONFIGURATION COMMANDS
Description Command
Write Single Configuration Item to RAM (temporary memory) Cxxxxxx
Read Single Configuration Item from RAM (temporary memory) cxxxx
Reset Reader R
Read Application Software Release (does not require Enter/Exit Service Mode) $+$!
Host Commands Obey CIFIH00
Host Commands Ignore CIFIH01
Enable all Symbologies AA
Disable all Symbologies AD
NOTE
To read a particular parameter setting from the reader, send the read
parameter command without any value. The reader will respond with its
currently configured value.
NOTE
The Read Application Software Release command is a direct command that
does not require entering Service Mode.
INTERFACE SELECTION COMMANDS
Description Command
Restore Custom Default Configuration HA00
RS232 HA05
USB-COM HA47
USB-KBD HA35
USB-KBD-ALT HA2B
USB KBD-APPLE HA2C
NOTE
The Interface Selection commands store and load the new interface type
with its factory defaults into the current configuration.
