TC1200 REFERENCE MANUAL
18
3
RS232 ONLY PARAMETERS
Description Parameter Value
Baud Rate 1200 R2BA 00
2400 01
4800 02
9600 03
19200 04
38400 05
57600 06
115200 07
Parity none R2PA 00
even 01
odd 02
Data Bits 7 R2DA 00
8 01
Stop Bits 1 R2ST 00
2 01
RS232/USB-COM PARAMETERS
Description Parameter Value
Intercharacter Delay No delay or from 10 to 990 ms R2IC a
Disable Character host command character which disables the reader R2DC b
Enable Character host command character which enables the reader R2EC b
ACK/NAK Options disable R2AE 00
enable for label transmission 01
enable for host command acknowledge 02
enable for label transmission and host command acknowledge 03
ACK Character Selects character to be used as ACK R2AC c
NAK Character Selects character to be used as NAK R2NA c
ACK/NAK Timeout Value No timeout or from 200 to 15000 ms R2AT d
ACK/NAK Retry Count From 0 to unlimited retries R2AR e
ACK/NAK Error Handling Ignore errors detected R2EH 00
Process errors as valid ACK character 01
Process errors as valid NAK character 02
a = Hex value from 00 to 63 representing the decimal number (00 = no delay; all others x10 ms)
b = Hex value from
00 to FE representing the ASCII character
c = Hex value from
00 to FF representing the ASCII character
d = Hex value from
00 to 4B representing the decimal number (00 = timeout disabled; all others x200 ms)
e = Hex value from
00 to FF representing the number of retries (00 = no retries; 01-FE = 1-254 retries; FF = unlimited retries)
