SOFTWARE CONFIGURATION STRINGS
19
3
USB-KBD / USB-KBD-ALT / USB-KBD-APPLE PARAMETERS
Description Parameter Value
Keyboard Country Mode *US KBCO 00
*Belgium 01
*Britain 02
Croatia 11
Czechoslovakia 0E
Denmark 03
*France 04
*Germany 05
Hungary 0D
*Italy 06
Japanese (106 key) 0C
Norway 07
Poland 12
Portugal 08
Romania 10
Slovakia 0F
*Spain 09
*Sweden 0A
Switzerland 0B
Keyboard Intercode Delay No delay or from 1 to 99 seconds KBID f
CTRL + KEY KBSC 00
CTRL + SHIFT + KEY 01
Send Control Characters
Special Function KEY
02
1 ms KBSP 01
2 ms 02
3 ms 03
4 ms 04
5 ms 05
6 ms 06
7 ms 07
8 ms 08
9 ms 09
USB Keyboard Speed
10 ms
0A
f = Hex value from 00 to 63 representing the decimal number (00 = no delay; all others x1 s)
* = Valid for USB-KBD-APPLE
READING PARAMETERS PARAMETERS
Description Parameter Value
Illumination Mode Disabled SPIL 00
Triggered 01
Enabled 02
Operating Modes On Line SNRM 00
Serial On Line 01
Automatic 02
Automatic (Object Sense) 03
Test 04
Automatic Threshold From 2 to 255 scans without a code SNAT g
Phase Off Event Trigger Stop SNTO 00
Timeout 01
Trigger Stop-Timeout 02
Timeout From 40 to 5100 ms SNET h
Serial Start Any string of characters (max 20) between 00-FE STON i
Serial Stop Any string of characters (max 20) between 00-FE STOF i
LED Indication On Decode BPIN 00
After Transmission 01
Label Programming Mode Disabled FAPM 00
Enabled 01
g = Hex value from 02 to FF representing the number of scans without a code
h = Hex value from
02 to FF representing the decimal number (x20 ms)
i = Hex value from
00 to FE representing the ASCII character
