TC1200 REFERENCE MANUAL
20
3
DATA FORMAT
Description Parameter Value
Data Transmission On Decode LFTX 01
After Phase Off 00
Code Verifier Mode Disabled LFCV 00
Transmit Wrong String 01
Transmit Wrong Code 02
Match String Any string of characters (max 20) between 00-FE COVS k
Wrong Code String Any string of characters (max 20) between 00-FE WCVS k
Case Conversion Disable LFCA 00
Upper Case 01
Lower Case 02
Global Prefix (Header) Any string of characters (max 20) between 00-FE LFPR k
Global Suffix (Terminator) Any string of characters (max 20) between 00-FE LFSU k
No Read String Any string of characters (max 20) between 00-FE NORS k
Character Conversion An 8-character string between 00-FF LFCH m
Transmit AIM IDs Disable AIEN 00
Enable 01
Transmit Custom Label IDs Disable IDCO 00
Prefix 01
Suffix 02
GS1-128 AIM ID Disable U8AI 00
Enable 01
k = Hex value from 00 to FE representing the ASCII character
m = 8 Hex values from
00 to FF representing the 8 ASCII characters (FF = no replacement or ignore)
Custom Code Identifiers Any string of characters (max 3) between 00-FE
UPC-A ABID k
UPC-E EBID k
EAN-8 8BID k
EAN-13 3BID k
UPC-A/P2 A2ID k
UPC-A/P5 A5ID k
UPC-E/P2 E2ID k
UPC-E/P5 E5ID k
EAN-8/P2 82ID k
EAN-8/P5 85ID k
EAN-13/P2 32ID k
EAN-13/P5 35ID k
ISBN ISID k
ISSN INID k
GTIN for EAN/UPC w/o Add-On GBID k
GTIN for EAN/UPC w P2 G2ID k
GTIN for EAN/UPC w P5 G5ID k
Code 39 C3ID k
Code 32 P3ID k
Code 128 C8ID k
GS1-128 U8ID k
ISBT 128 I8ID k
Interleaved 2 of 5 I2ID k
Standard 2 of 5 S2ID k
Codabar CBID k
ABC Codabar ACID k
Code 11 C1ID k
GS1 Databar 14 (Omnidirectional) 4BID k
GS1 Databar Expanded XBID k
GS1 Databar Limited LBID k
Code 93 C9ID k
MSI MSID k
k = Hex value from 00 to FE representing the ASCII character
