Datalogic TC1200 User Manual

SOFTWARE CONFIGURATION STRINGS
27
3
CODE SELECTION
Description Parameter Value
Codabar
Codabar Disable CBEN 00
Enable 01
Code Length Control Variable CBLC 00
Fixed 01
Set Length Length 1 (or Min Length) from 3 to 50 characters CBL1 v
Length 2 (or Max Length) 0 or from 3 to 50 characters CBL2 v
ABC Codabar
ABC Codabar Disable CBAB 00
Enable 01
Concatenation Mode Static CBCM 00
Dynamic 01
Dynamic Concat. Timeout From 50 to 2550 ms CBDT t
Check Options
Check Calculation Disable CBCC 00
Enable AIM Standard Check 01
Enable Mod-10 Check 02
Check Tx Disable CBCT 00
Enable 01
Start/Stop Set ABCD/TN*E CBSC 00
ABCD/ABCD 01
abcd/tn*e 02
abcd/abcd 03
Start/Stop Tx Disable CBSS 00
Enable 01
Start/Stop Match Disable CBSM 00
Enable 01
Decoding Options
Minimum Reads One Read CBMR 01
Two Reads 02
Three Reads 03
Four Reads 04
Decoding Level Disable CBDL 00
Level 1 01
Level 2 02
Level 3 03
Level 4 04
Level 5 05
Character Correlation Disable CBCO 00
Enable 01
Interdigit Ratio Any ratio or 1 to 10 CBIR r
Quiet Zones Quiet Zone on One Side CBLO 01
Quiet Zones on Two Sides 02
Auto 03
Virtual Quiet Zones on Two Sides 04
Small Quiet Zones on Two Sides 05
Stitching Disable CBST 00
Enable 01
v = Hex value from 00 or 03 to 32 representing the decimal number
t = Hex value from
05 to FF representing the decimal number (x10 ms)
r = Hex value from
00 to 0A representing the decimal number of the interdigit space/module ratio (00 = any ratio)
