vPad-A1 OPERATORS MANUAL
Figure 25
Figure 26
A downward arrow within a grey box indicates that touching the box will display a list of options.
Figure 26
shows the pop-up list that appears for choosing an Arrhythmia waveform.
A gray scrollbar on the right of a list such as
Figure 26
indicates that more options can be revealed
by dragging the list up or down.
The currently active option is displayed with a green radio indicator, per
Figure 26
. Touch any
option in the list to select it and dismiss the pop-up. To dismiss the pop-up without selecting an
item, press the Back button at bottom right on the Tablet.
Manual Operation/Chapter 4 # Page 31
