vPad-A1 OPERATORS MANUAL
5.1.2.4 Creating Test Records
The button on the Equipment Information form (
Figure 111
)
displays a menu for creating new Test Records. It displays the new Test
Record
filename that will be saved, as well as the location of the Records
directory on the Tablet.
At this point, users can override the Overall Test Result from “PASS” to
“FAIL” and, optionally, enter reasons in the Comments box. Only a
“PASS” result can be overridden; a record with one or more failed tests will
always report the Overall Test Result as “FAIL”, which cannot be changed.
Users may also enter the Labor Time and edit the default Test Report Title, if
necessary. In the final Test Report, the combined total Labor Time (hours +
minutes) will be entered as decimal hours (e.g. 1 hr 30 mins º 1.5 hrs) to
support CMMS system requirements.
The button will discard the entered Equipment Information and exit the Test Record
creation interface. This will not undo changes made to the equipment database. To temporarily
dismiss the Test Record creation interface while retaining the saved Equipment Information, use the
Back button instead.
Finally, pressing the button will save the Test Record file to Tablet memory,
which can later be recalled and viewed in the vPad-Record Manager App. The operation will also
clear all current Test Results from the View Results screen.
5.1.2.5 Managing Test Records
vPad Record Manager is an app which is installed on the Tablet and which may be run
independently of the vPad-A1 app.
Record Manager may be used to copy, print, and/or delete Test Record files saved by vPad-A1.
Record Manager can also be used to convert Test Records to Adobe PDF documents.
Press the icon on the Home screen to launch the Record Manger app.
Refer to MN-087 6100-081
vPad-RM Operators Manual
for further information on use of the
Record Manager.
Figure 118
Automation and Test Records/Chapter 5 # Page 78
