vPad-A1 OPERATORS MANUAL
FIBRILLATIONS
• Coarse Atrial Fibrillation
• Fine Atrial Fibrillation
• Coarse Ventricular Fibrillation
• Fine Ventricular Fibrillation
TACHYCARDIA
• Atrial Tachycardia
• Paroxysmal Atrial Tachycardia
• 90 BPM Supraventricular Rhythm
• 120 BPM Supraventricular Rhythm
• 140 BPM Supraventricular Tachycardia
• 150 BPM Supraventricular Tachycardia
• 160 BPM Supraventricular Tachycardia
• 170 BPM Supraventricular Tachycardia
• 180 BPM Supraventricular Tachycardia
• 190 BPM Supraventricular Tachycardia
• 200 BPM Supraventricular Tachycardia
• 210 BPM Supraventricular Tachycardia
• 220 BPM Supraventricular Tachycardia
• 160 BPM Normal Sinus Rhythm
GENERAL 2
• Atrial Flutter
• Sinus Arrhythmia
• Miss 1 Beat, 80 BPM
• Miss Every 10
th
Beat, 80 BPM
• Miss Every 10
th
Beat,
120 BPM
• Nodal Rhythm
• Sinus Bradycardia, <60 BPM
The Rate of Arrhythmia simulations is fixed, as Rate may be an important indicator
of the cardiac disease or condition being simulated. Accordingly, the Rate button is
greyed out when an Arrhythmia waveform is selected, however, adjustment of both
Amplitude and Artifact remains possible. The simulation Mode is also selectable
between Adult and Neonatal, although this setting will affect only those
Arrhythmias which contain complete or partial simulations of NSR beats.
Arrhythmia waveforms that are manually activated will display a Trigger button that
starts a simulation each time it is pressed.
Figure 34
Manual Operation/Chapter 4 # Page 35
