Digital DECpc LPx/LPx+ Service Procedures
MCS Logistics Engineering - Nijmegen 45
LPx 560/566 Main Logic Board Jumper Settings
NOTE
The HD Active Display connector (J44) is used for external SCSI/IDE adapters to
display hard drive activity.
CAUTION
Do not use the password clear jumper (J32); use instead the clear CMOS jumper (J29).
Using the clear CMOS jumper then sets all other CMOS settings back to the defaults.
Settings shown in bold italics are factory defaults.
Feature
Description
Setting
Flash ROM upgrade
Enable
Disable
J35, jumpered
J35, open
Recovery mode
Normal
Recovery mode
J34, open
J34, jumpered
Display type
Mono
Color
J33, open
J33, jumpered
Password clear
Normal
Password clear (MFG test)
J32, open
J32, jumpered
Clear CMOS to default
settings
Normal operation
Clear CMOS
J29, open
J29, jumpered
CPU type
Intel
Alpha
J39, open
J39, jumpered
Reprogram boot block
Disable
Enable
J40, pins 1 & 2 jumpered
J40, pins 2 & 3 jumpered
