Service Procedures Digital DECpc LPx/LPx+
54 MCS Logistics Engineering - Nijmegen
Removing a 3½-Inch Mass Storage Device (Internal Drive Bay)
To remove a 3½-Inch Mass Storage Device from the internal drive bay:
1) Turn off the computer.
2) Disconnect external devices, ac power, and monitor power.
3) Unlock and remove outside cover.
4) Disconnect power and ribbon cables.
5) Remove four mounting screws.
6) Pull drive from internal drive bay.
Figure 3 - 15 Removing a 3½-Inch Mass Storage Device from the Internal Drive Bay
